Датчик M.D. Micro Detectors SpA FQR2/BP-0E MD MICRO DETECTORS 335060
Артикул: 335060
Цена: по запросу
Есть в наличии
Работаем с 44ФЗ, 223ФЗ, 275ФЗ
Аккредитация на АСТ ГОЗ
Доставка вМосква
Самовывоз из магазина0 руб.
по предварительному заказу
(г. Москва, м. Таганская,
ул. Большие Каменщики, д. 6, стр. 1)
(г. Москва, м. Таганская,
ул. Большие Каменщики, д. 6, стр. 1)
Курьером (1-2 рабочих дня)0 руб.
Самовывоз из ПВЗ (1-2 рабочих дня)0 руб.
ХАРАКТЕРИСТИКИ
Гарантия
- 12 месяцев
Сертификаты
- CE
Nominal sensing distance
- 100mm white target90% Kodak 100x100mm
Thermal drift of Sr
- ?10% Sr
Repeat Accuracy
- 5%
Sensitivity adjustment
- No
Function Principle
- Diffuse reflection
Optic position
- Axial
Output type
- PNP
Output Function
- NO+NC
Switching frequency
- 250Hz
Operating Voltage
- 10-30Vdc
No-Load supply current
- ?30mA
Load current
- ?50mA
Leakage current
- ?10?A
Output voltage drop
- 2V max. IL =50 mA
Max ripple content
- 10%
LED indicators
- Yellow (Lon) or output status Lo/Do
Time delay before availability
- ?200ms
Short-circuit protection
- Short circuit (autoreset), Overvoltage
Reverse Polarity Protection
- Polarity inversal, Inpulsive voltage
Emission
- Red (660 nm)
Interference to external light
- 5000lux (incandescent lamp), 10000lux (sunlight)
Dimensions
- M18 x 1 /L =66,3mm
Weight
- 20g
Housing Material
- PBT
Connections
- M12 Plug
Active Head Material
- PC
Tightening torque
- 1Nm
Operating temperature
- - 25°C…+ 70° C (Without freeze)
Approvals
- CE,
EMC compatibility
- EN 60947-5-2
Shocks and vibrations
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
Degree of protection
- IP67
Supplied Accessories
- Nuts M18 x 1
ОПИСАНИЕ
Датчик M.D. Micro Detectors SpA FQR2/BP-0E от MD Micro Detectors — оборудование класса Фотоэлектрические датчики, сочетающее прочность и точность. Компания Mdmicfrussia.ru предлагает продукцию, подходящую для различных отраслей и сфер применения
Что получает клиент:
- Доставка напрямую от производителя без лишних посредников
- Оперативная обработка заявок и доставка по РФ
- Официальные поставки оригинальной техники
- Конкурентные цены и прозрачные условия работы
- Сопровождение специалистов от подбора до внедрения
Характеристики - M.D. Micro Detectors SpA FQR2/BP-0E
Detection properties Application Outputs Electrical data Mechanical data Test/Approvals Accessories
